Simucube 3 Pro 25 Nm

Simucube 3 Pro 25 Nm

€1.621,95
Temporarily out of stock
Total
Temporarily out of stock

Simucube 3 Pro 25 Nm, 23-bit sensor is the flagship of direct drive force feedback – a wheelbase that transforms steering from an accessory into a professional racing instrument. With 25 Nm, industrial servo motors developed exclusively for Simucube and a completely redesigned control algorithm, the SC3 Pro delivers precision and silence that sets a new standard for sim racing.

Telemetry-based effects such as ABS, RPM, and road texture provide information directly to your hands – so you react instinctively, not reactively. Mounts from the front or underneath.

Designed in Finland, manufactured in the EU.

NOTE: Requires Simucube Link Hub for operation. Not included.

Specifications

Motor type: High response speed, Direct drive optimized SPM
Max torque: 25 Nm
Angle sensor: 23-bit absolute (8 000 000 steg)
Power supply: 360 W (450 W peak)
Dimensions (B x D x H): 135 x 135 x 303 mm
Package dimensions: 190 x 300 x 390 mm
Weight: 11 kg
Mounting: Front and bottom
Warranty: 3 years
Country of origin: Finland

Compatibility

PC (Windows) via Simucube Link Hub
Compatible with all wheels with standard PCD flange
Mounting system: Front and bottom (135 mm and 78.4 mm bolt circle)
Flange centering: Ø110 mm
Optional: Simucube Link Hub (required for full system integration with ActivePedal/Valo GT-23)
Optional: Simucube Control Box included – enables adjustment of settings while driving

In the package

Simucube 3 Pro Wheel Base x1
Power adapter x1
RJ45 cable x1
AC power cable x1
Quick start guide x1
Control Box x1
Mounting kit:
- M8 washer x4
- M6 washer x4
- M5 washer x2
- M8x35 hex bolt x4
- M8x30 hex bolt x4
- M5x30 hex bolt x2
- M6 x 16 hex bolt x4
- M5 T-slot nut 8 mm x2

Included NOT: Link Quick Release for Simucube 3, Simucube Link Hub

Maintenance

Clean with a dry microfiber cloth.
Avoid solvents on all surfaces.
Regularly check that mounting screws are tightened.
Keep quick release-the connectors clean and free from dirt.
Update firmware via Simucube Link-software regularly.
Contact support when unusual noises or vibration patterns.
